Processor/Cache |
|
CPU |
Dual Socket P (LGA 3647)
2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors‡,
3 UPI up to 10.4GT/s
Support CPU TDP 70-205W |
Cores |
Up to 28 Cores |
Note |
‡ BIOS version 3.2 or above is required to support 2nd Gen Intel® Xeon® Scalable processors (codenamed Cascade Lake-R) |
Â
Â
|
System Memory |
|
Memory Capacity |
16 DIMM slots
Up to 4TB 3DS ECC DDR4-2933MHz† RDIMM/LRDIMM
Supports Intel® Optane™ DCPMM††|
Memory Type |
2933†/2666/2400/2133MHz ECC DDR4 RDIMM/LRDIMM |
Note |
† 2933MHz in two DIMMs per channel can be achieved by using memory purchased from Supermicro
†† Cascade Lake only. Contact your Supermicro sales rep for more info. |
Â
|
On-Board Devices |
|
Chipset |
Intel® C621 chipset |
SATA |
SATA3 (6Gbps); RAID 0, 1, 5, 10 |
Network Controllers |
Intel® X550 Dual Port 10GBase-T
Virtual Machine Device Queues reduce I/O overhead
Supports 10GBASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output |
IPMI |
Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support |
Graphics |
ASPEED AST2500 BMC |
Â
|
Input / Output |
|
SATA |
10 SATA3 (6Gbps) ports |
LAN |
2 RJ45 10GBase-T ports
1 RJ45 Dedicated IPMI LAN port |
USB |
5 USB 3.0 ports (2 rear, 2 via header, 1 Type A)
4 USB 2.0 ports (2 rear, 2 via headers) |
Video |
1 VGA port |
Audio |
7.1 HD Jacks |
Serial Port/Header |
2 COM ports (1 rear, 1 Header) |
Â
|
System BIOS |
|
BIOS Type |
AMI 32Mb SPI Flash ROM |
Â
Â
|
PC Health Monitoring |
|
CPU |
Monitors for CPU Cores, Chipset Voltages, Memory.
4+1 Phase-switching voltage regulator |
FAN |
Fans with tachometer monitoring
Status monitor for speed control
Pulse Width Modulated (PWM) fan connectors |
Temperature |
Monitoring for CPU and chassis environment
Thermal Control for fan connectors |
|
