Supermicro SYS-5019P-M 1U Rackmount Mainstream

Key Applications

Web Hosting, VM
Compact Network Appliance

Categories: , ,

Description

Key Features

  • Single Socket P (LGA 3647) supports2nd Gen Intel® Xeon® Scalable
    processor (Cascade Lake/Skylake)‡
  • 6 DIMMs; up to 1.5TB 3DS ECC
    DDR4-2933MHz†RDIMM/LRDIMM
  • 1 PCI-E 3.0 x16 slot (FH, HL)
  • 4 Hot-swap 3.5″ SATA3 bays w/ RAID
  • 2x 1GbE with Marvell® 88E1512
  • Integrated IPMI 2.0 and KVM with Dedicated LAN
  • 1 VGA, 1 COM, 2 USB 3.0, 2 USB 2.0
  • 350W High-efficiency Power Supply Platinum Level Certified



Specifications

Product SKUs
SYS-5019P-M SuperServer 5019P-M (Black)



Motherboard
Super X11SPM-F



Processor
CPU Single Socket P (LGA 3647)

2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors‡

Support CPU TDP 70-165W
Cores Up to 28 Cores
Note ‡ BIOS version 3.2 or above is required to support 2nd Gen Intel® Xeon® Scalable processors (codenamed Cascade Lake-R).

Extended thermal solutions may be required to support CPUs higher than 165W TDP, please contact Supermicro Technical Support for additional information.



System Memory
Memory Capacity 6 DIMM slots

Up to 1.5TB 3DS ECC DDR4-2933MHz† RDIMM/LRDIMM
Memory Type 2933†/2666/2400/2133MHz ECC DDR4 RDIMM/LRDIMM
Note † 2933MHz in two DIMMs per channel can be achieved by using memory purchased from Supermicro



On-Board Devices
Chipset Intel® C621 chipset
SATA SATA3 (6Gbps) via C621 controller

RAID 0, 1, 5, 10 support
Network Controllers Dual Gigabit Ethernet LAN with Marvell® 88E1512
IPMI Support for Intelligent Platform Management Interface v.2.0

IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Video ASPEED AST2500 BMC



Input / Output
SATA 12 SATA3 (6Gbps) ports
LAN 2 RJ45 1GbE LAN ports

1 RJ45 Dedicated IPMI LAN port
USB 5 USB 3.0 ports (2 rear + 2 headers + 1 Type A)

6 USB 2.0 ports (2 rear + 4 headers)
Video 1 VGA port
Serial Port / Header 2 COM ports (1 rear, 1 header)
SuperDOM 2 SuperDOM (Disk on Module) ports with built-in power



System BIOS
BIOS Type AMI UEFI



Management
Software Intel® Node Manager

IPMI 2.0

KVM with dedicated LAN

NMI

SPM, SUM

SuperDoctor® 5

Watch Dog
Power Configurations ACPI Power Management



PC Health Monitoring
CPU Monitors for CPU Cores, Chipset Voltages, Memory.

4+1 Phase-switching voltage regulator
FAN Fans with tachometer monitoring

Status monitor for speed control

Pulse Width Modulated (PWM) fan connectors
Temperature Monitoring for CPU and chassis environment

Thermal Control for fan connectors
Chassis
Form Factor 1U Rackmount
Model CSE-813MFTQC-350CB2



Dimensions and Weight
Height 1.7″ (43mm)
Width 17.2″ (437mm)
Depth 19.85″ (503mm)
Package 8.5″ (H) x 24″ (W) x 29.5″ (D)
Weight Gross Weight: 30.4 lbs (13.8 kg)

Net Weight: 17.6 lbs (8 kg)
Available Colors Black



Front Panel
Buttons Power On/Off button

System Reset button
LEDs Power LED

Hard drive activity LED

Network activity LEDs

System Information LED



Expansion Slots
PCI-Express 1 PCI-E 3.0 x16 slot (FH, HL)
M.2 1x M.2 Interface: PCI-E 3.0 x4

Form Factor: 2242, 2280

Key: M-Key

Double Height Connector



Drive Bays / Storage
Hot-swap 4 Hot-swap 3.5″ SATA3 drive bays



Peripheral Drives
Optional Optional slim optical device bay, optional FDD/USB bay



System Cooling
Fans 4x 40x28mm PWM fans

Optional 2 fans for AOC cooling



Power Supply
350W AC power supply w/ PFC
AC Voltage 100-240 V, 50-60 Hz, 5.0-2.5 Amp
+5V Max.: 15 Amp

Min.: 0.2 Amp
+5V standby Max.: 3 Amp

Min.: 0 Amp
+12V Max.: 29 Amp

Min.: 0.5 Amp
-12V Max.: 0.2 Amp

Min.: 0 Amp
+3.3V Max.: 12 Amp

Min.: 0.2 Amp
Certification     Platinum Level Certified
  [ Test Report ]



Operating Environment
RoHS RoHS Compliant
Environmental Spec. Operating Temperature:
   10°C ~ 35°C (50°F ~ 95°F)

Non-operating Temperature:
   -40°C to 70°C (-40°F to 158°F)

Operating Relative Humidity:
   8% to 90% (non-condensing)

Non-operating Relative Humidity:
   5% to 95% (non-condensing)
